Auxiliary Power Supply

FXP

SCM

Images are for reference only See Product Specifications

Auxiliary Power Supply

FXP

Manufacturer

SCM

Benefits

Designed according to EN50467
Unshielded and shielded cables
Static and dynamic applications
Over voltage safety features (i.e Permanent Magnet Motor)
Light, compact and high electrical performances
Halogen-free

Description

Locking system with captive screws
Crimp contacts: cable cross-section from 10 to 120 mm²
Copper and aluminum cables

Main characteristics

Rated current: up to 400A
Service voltage : Up 3000V (OV2PD3 & OV3PD2 according to EN50467) Up 4000V (OV2PD2 according to EN50467)
Up 3000V (OV2PD3 & OV3PD2 according to EN50467)
Up 4000V (OV2PD2 according to EN50467)
Protection index: IP68
Service temperature: -40ºC / +100ºC
Salt spray resistance: 500 hours

The next evolution in electric motor use is the Permanent Magnet (PM) Motor

Uses less energy
Facilitates motor cooling
Improves motor performance
Reduces vehicle life-cycle costs
Shifts braking power from the mechanical to the electrical system

Benefits

Standard platform
Modularity
EN & WW F&S compliant resin
Compact: space saving
Field proven
Few components (50)
Flexible installation
Easy maintenance
Protective against return currents
